EuroCarrier 2611 - Sea Eidum

Sea Eidum is an EuroCarrier 2611, specially designed for optimal functionality, the Sea Eidum is equipped with two powerful HEILA deck cranes, has a Bollard Pull of 33.9 tons and can operate in shallow waters with a draft of 2.60 meters. Sea Eidum boasts an impressive deck space, allowing for efficient cargo handling, equipment storage, and various offshore activities. Its advanced propulsion system guarantees enhanced maneuverability and stability, enabling precise positioning even in challenging conditions.

The Sea Eidum is powered by Tier III main engines, ensuring compliance with stringent emissions standards while maintaining exceptional performance. This eco-friendly feature underscores our commitment to sustainability, reducing environmental impact during the vessel's operations.

Safety is paramount, and the Sea Eidum excels in this aspect. Equipped with the latest safety features and adhering to stringent industry regulations, this vessel provides a secure and secure working environment for crew members and project personnel alike.

Whether it's supporting offshore construction, subsea operations, or transportation logistics, the Sea Eidum delivers outstanding capabilities that ensure seamless execution of projects in any environment.

Technical specifications Contact us

EUROCARRIER 2611 Sea Eidum

VESSEL SPECIFICATIONS

Type EuroCarrier 2611
Classification Bureau Veritas • Hull • Mach • / Unrestricted Navigation / AUT-UMS (SS)
IMO number 9969314
Year built 2023 - Neptune Hardinxveld, NL
Flag Dutch
Port of registry Vlissingen
Call sign PFVV
MMSI 246982000
Length overall 26,48 m
Breath overall 11,00 m
Minimum draft 2,50 m
Operational Draft 2,60 m
Maximum draft 3,25 m
Minimum air draft 9,00 m
Maximum air draft 17,50 m
Gross tonnage 255 t
Net tonnage 76 t
System N/A
Type N/A
Capacity N/A
Typel AFT: Heila HLRM 140-3S / FWD: Heila HLRM 230-4SLK
Capacity AFT: 26t @ 5.65m / FWD: 24.4t @ 7.89m
Fuel oil 110,0 + Urea 8 m³
Fresh water 39,0 m³
Lubricating oil 1,6 m³
Hydraulic oil 1,6 m³
Dirty oil 1,6 m³
Sewage 7,0 m³
Bilge water 9,0 m³
Main engines 2x Caterpillar C32 Tier III
Total power 2x 970kW @ 1800 RPM
Propulsion 2x fixed propellor - 1850mm dia in nozzle
Bowthruster 250kW, tunnel thruster in SB pushbow
Main generator sets 2x Volvo D8 MG Tier III - 278kVa - 50Hz + CAT C4.4
Fuel oil transfer pump 100m3/hr @ 5.2 bar
Fresh water transfer pump 80m3/h @ 2.1 bar
Fresh water maker N/A
Air compressor Atlas copco 7.14kW
Powerpack 2x 90kW - electric hydraulic
Free deckspace 145 m2
Deck strength 6t/m2
Towing winch Tecnospirit 50t / 60t (pull/hold) 500 m x 36 mm
Anchor Handling Winch Tecnospirit 100t / 150t (pull/hold) 350 m x 52 mm
Tugger winch Tecnospirit 15t / 22.5t (pull/hold) 150 m x 28 mm
Towing pins SWL 50t + chain stopper 95t
Pushbow double push bow - fully fendered
Stern roller dia 838mm, length 5m / BOW Roller: dia 1207mm, 6 m
Bollard pull 33.9 t
Maximum speed 10,00
Economic speed 8,00
Horsepower 1940 kW
Persons 6
Single cabin 6
Double cabin N/A
Air conditioned Yes

The information is for guidance purposes only and may be subject to changes.

PROVEN TRACK RECORD

The Sea Eidum has a proven track record and has worked in areas with limited maneuverability. Contact our Commercial Department for any additional information you might need. Sea Eidum is ready to support your project anywhere in the world in a diverse working environment.
